Operating sequence fertiliser spreader ZA-M
AMATRON II-A DB 599 09.01
6.7 Spreading extremely small
spread rates
I
AMATRON II-A is not suited for
spreading slug pellets.!
I
Spread rates below 50 kg/ha will have
an unfavourable flowing effect of the
material due to the small diameter of
the discharge opening and therefore
may lead to deviations of the spread
rate.
Spreading green manure
Example: Rye grass
Spread rate: 43 kg/ha
Working width: 12 m
Forward speed:10 km/h
Shutter position
(from setting chart): “27“
Table 2: Spread rate setting for rye grass – ex-
cerpt from the setting chart
0,51 kg/l
10 12
km/h km/h km/h km/h km/h
8101281012810128101281012
25
25
20
16
21
16
14
26
39
31
26
33
26
22
27
52
41
35
43
34
29
28
64
51
43
53
42
35
29
79
63
53
66
52
44
30
96
77
64
80
64
53
Shutter position
rye grass
m
F
For spreading rye grass, please pro-
ceed with the calibration test in the
following order:
1 - In the setting chart find the page for spread
rate setting of CAN 27 N granular BASF.
2 - Look for column 20 m working width and 8
km/h. In this column for the setting lever posi-
tion "27" (shutter position "27" for rye grass
spread rate 34 kg/ha) read off the spread rate
165 kg/ha.
3 - Calibrate with the read off spread rate 165
kg/ha (see para. 6.1.XX), and then enter the
desired spread rate 34 kg/ha.
Table 3: "Spread rate setting CAN 27% N
granular BASF" – excerpt from setting chart
CAN 27 % gran. BASF; Hydro; DSM; Kemira;
Agrolinz
1,06 kg/l
CAN 27 % N gran. ø 3,36 mm SCHZ Lovosice CZ
1,04 kg/l
KAS 27 % N gepr. ø 2,76 mm NET IRL
1,03 kg/l
NP- und NPK-Sorten gran. BASF
1,13 kg/l
NPK 15-15-15 gran. ø 3,65 mm Combilinz Agrolinz
1,11 kg/l
NPK-1 12-19-19 gran. ø 2,81 mm
SCHZ Lovosice CZ
1,05 kg/l
20 21
24
27 28
km/h km/h km/h km/h km/h
8101281012810128101281012
24 119 95 79 113 91 76 99 79 66 88 71 59 85 68 57
25 133 107 89 127 102 85 111 89 74 99 79 66 95 76 63
26 149 119 99 142 113 94 124 99 83 110 88 73 106 85 71
27 165 132 110 157 126 105 137
110
92 122 98 81 118 94 79
28 182 146 121 173 139 116 152
121
101 135 108 90 130 104 87
29 200 160 134 191 153 127 167
134
111 148 119 99 143 114 95
30 219 175 146 209 167 139 183
146
122 162 130 108 157 125 104
31 239 191 160 228 182 152 199
160
133 177 142 118 171 137 114
32 260 208 173 248 198 165 217
173
144 193 154 128 186 149 124
33 282 225 188 268 215 179 235
188
156 209 167 139 201 161 134
34 304 243 203 289 232 193 253
203
169 225 180 150 217 174 145
35 327 262 218 311 249 208 272
218
182 242 194 161 233 187 156
36 351 280 234 334 267 223 292
234
195 260 208 173 250 200 167
37 375 300 250 357 286 238 312
250
208 278 222 185 268 214 178
38 400 320 266 381 305 254 333
266
222 296 237 197 285 228 190
39 425 340 283 405 324 270 354
283
236 315 252 210 304 243 202
40 451 361 301 429 344 286 376
301
250 334 267 223 322 258 215
41 477 382 318 454 364 303 398
318
265 353 283 236 341 273 227
42 504 403 336 480 384 320 420
336
280 373 298 249 360 288 240
43 531 424 354 505 404 337 442
354
295 393 314 262 379 303 253
44 558 446 372 531 425 354 465
372
310 413 331 275 398 319 266
45 585 468 390 557 446 371 488
390
325 433 347 289 418 334 279
46 612 490 408 583 467 389 510
408
340 454 363 302 437 350 292
47 640 512 427 610 488 406 533
427
356 474 379 316 457 366 305
48 667 534 445 636 509 424 556
445
371 494 396 330 477 381 318
49 695 556 463 662 529 441 579
463
386 515 412 343 496 397 331
50 722 578 481 688 550 459 602
481
401 535 428 357 516 413 344
51 749 599 500 714 571 476 624
500
416 555 444 370 535 428 357
52 776 621 517 739 591 493 647
517
431 575 460 383 554 443 370
53 803 642 535 764 611 510 669
535
446 594 476 396 573 459 382
Shutter position
m
