38
Operating sequence field sprayer
AMATRON II-A DB 599 09.01
sprayed within one job) and store by pressing key
=
Eingabe
Input
.
F
Enter the value for the desired spray
rate with the vehicle stopped.
F
During spraying procedure the spray
rate can be adjusted via the keys
-10 %
+10 %
in + / - 10 %-steps (please
refer to para. 7.5.4).
• By pressing key
T4
(Next), a comment can
then be filed in the data block "job" (see para.
7.1.3).
7.1.3 Menu "Comment"
Fig. 53
Here you can file a comment (Fig. 53/1), e.g. de-
tails about the weather etc. Entering via the 10-digit
key board (see para. 7.1.1). Name and comment
are not necessary for the operational procedure,
however, they ease the later reading and assign-
ment of data.
Also in this case the data are only stored by
pressing
=
Eingabe
Input
• By pressing key
T2
(Start) the job can be
started also from here. The actual operational
data are displayed.
• By pressing key
T4
(Next) now the imple-
ment serial number is displayed (please refer to
para. 7.1.4).
7.1.4 Menu "implement serial number"
Fig. 54
With the initial operation of the machine (Fig. 54/2)
the implement serial number (Fig. 54/1is automati-
cally issued and will later on be automatically se-
lected, i.e. no entry is necessary.
If different implement of the same type are con-
nected with AMATRON II-A (e.g. a second field
sprayer with different implement data), the individ-
ual machines must receive different implement
serial numbers (e.g. enter the next free implement
number for the second sprayer).
After connection the second sprayer can be acti-
vated by entering its serial number via the ten digit
key board.
• By pressing key
T1
(Menu) and key
T4
(go) you can return to the menu selection.
• Start the job by pressing key
T2
(Start).
However, beforehand enter the necessary data
into the data block "machine" as otherwise error
messages would occur (see para. 7.6).
• By pressing key
T3
(Delete) all data can be
deleted. Correction are also possible while en-
tering via key
C
.
F
It is useful to select in the menu se-
lection the data block "machine via
the key
T3
in order to enter the
required data for the job (see para.
7.2).
