Description of produce
Cirrus 3/4/6000 DB2034 08.04
35
3.4 Type plate and CE-sign
The type plate (Fig. 41) and the CE sign are located on
the right hand machine side on the frame next to the
blower fan.
The following details are stated on the type plate:
Machine Ident-No. :.....................................................
Machine type: ..............................................................
Permissible pressure of system.......................... bar
Year of construction ...................................................
Factory..........................................................................
Basic weight: ...........................................................kg
Permissible total weight:........................................kg
Rear axle load:.........................................................kg
Front axle load / support load:...............................kg
Fig. 41
