Amazone Cirrus Series User Manual

Settings
Engagement position 1 to 3
1. Engage the handle (Fig. 129/1) in one of
the 3 positions.
Fig. 129
Sowing without plastic disc
1. Turn the handle beyond the engagement
catch (Fig. 130/1) and remove the plastic
disc from the RoTeC coulter.
Fig. 130
Installing RoTeC plastic disc
Secure the RoTeC plastic disc with the designation
• "K" on the short coulter
• "L" on the long coulter.
1. Push the plastic disc from below against the catch on the RoTeC
coulter.
The shoulder must grip in the slot.
2. Pull the handle to the rear and upwards beyond the notches.
A light blow on the centre of the disc helps to latch it into posi-
tion.
126 Cirrus BAH0049-1 09.14
