Amba Radiant Small - Assembly Instructions; Component Identification and Wiring; Mounting and Switch Operation

Page 2
BEFORE STARTING ASSEMBLY MAKE SURE ALL COMPONENTS LISTED ARE IN THE PACKAGE
DO NOT OVER-TIGHTEN SET SCREW TURN UNIT ON WITH SWITCH
1 2
3
4
SWITCH
! CAUTION — SURFACE OF UNIT IS HOT WHEN ON !
18 3/8”
468mm
9 1/2”
240mm
A
B
C
HEATED TOWEL RACKS
RADIANT SMALL
INSTALLATION INSTRUCTIONS
F
D
E
H
J
I
For hardwired installation cut plug from
end of cable and follow wiring guide below
WIRING GUIDE
HOT LOAD
(Black)
GROUND
(Green)
NEUTRAL LOAD
(White)
ELECTRICAL BOX
HEATED
TOWEL
RACK
BLACK
(Hot)
WHITE
(Neutral)
GREEN
(Ground)
A
A
B
B
C
C
(for plug-in installation ignore components H / I / J )
G
x4
