Amba RWH-SP - Installation Steps; Wall Mounting and Fixture Attachment; Securing and Powering the Unit

Page 2
BEFORE STARTING ASSEMBLY MAKE SURE ALL COMPONENTS LISTED ARE IN THE PACKAGE
DO NOT OVER-TIGHTEN SET SCREW TURN UNIT ON WITH SWITCH
1 2
3
4
22 3/8”
568mm
15 1/8”
384mm
A
B
C
F
D
E
SWITCH
! CAUTION — SURFACE OF UNI T IS HOT WHEN ON !
RADIANT Straight HARDWIRED
INSTALLATION INSTRUCTIONS
H
G
I
5 1/4”
133 mm
CENTER OF
WALL PLATE
