Amber Touch - Troubleshooting and Resets; Understanding Error Codes; Factory Reset Procedure

Error Codes
This relates to a fault with the internal
temperature sensor, either through damage
or disconnection. This usually requires a
replacement thermostat to correct.
This relates to a fault with the external oor
sensor probe. Contact your electrician, who
can isolate the electricity supply and check the
sensor is connected and working correctly.
Screen Lock
In some situations where your Amber-Touch is
installed into a location where restricted access
is necessary, simply:
Press and hold the and buttons until the
appears on the screen.
To unlock, simply repeat the process until the
disappears.
ER0
ER1
3 Simple Steps to Factory Reset
1. Having initiated the advanced settings, tap the
menu button continuously until you see AFAC
2. Hold the button until “---” is displayed on
the screen
3. Press the button and switch o at the
mains to complete factory reset
Please note: the time displayed will not reset and
will stay the same prior to factory reset.
Symbol Setting Default or
1
ADJ
Temperature
calibration
N/A
Adjust measured
temperature
2
SEN
Sensor mode IN
IN: built-in sensor
OUT: oor sensor
ALL: both
sensors
(oor sensor is
the limit sensor)
3
LIT
Max oor
temperature
35°C
Adjust limitation
value,
Limitation range:
5˚C~35˚C
4
DIF
Switching
dierential
1
Adjust switching
dierential
5
LTP
Frost
protection
mode
O
Turn on/o
frost protection
function
6
PRG
Heating
schedule
5/2
2: 5/2 day mode
1: 6/1 day mode
0: 7 day mode
7
RLE
Output N/A Not Used
8
D LY
Output delay 0
Change the
delay time
9
HIT
Max
temperature
setting
50°C
Max. Limitation
temperature
setpoint (50˚C)
10
AFAC
Reset to
factory
settings
N/A
Programming
parameters
will be reset to
factory settings
when symbol
“---” appears
Advanced Settings Overview Dimensions
86mm
13mm 30mm
98mm
Installation Guide
STEP 1
Release the front cover by inserting screwdriver
into the hole on the underside of the front plate
STEP 2
Take the backing plate apart according to diagram
STEP 3
Install the backing plate on to the electrical
connection box with screws before any wiring
takes place
STEP 4
Ensure all wiring is undertaken by a qualied
electrician
STEP 5
Install the housing cover and lock external frame
as per diagrams
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
