transmitters or receivers to avoid intermittent communication.
3. Line of Sight Rating. This device is rated at 300feet line of sight (no interference, barriers, or walls) but
typically you will get 100feet maximum under most real-world installations, which include passing through
barriers or walls.
4. Metal Barriers. Radio frequency will not pass through metal barriers such as aluminum siding. If you have
metal siding, align the remote and console through a window to get a clear line of sight.
The following is a table of reception loss vs. the transmission medium. Each “wall” or obstruction decreases
the transmission range by the factor shown below.
Display Console Set Up
Display Console Layout
The display console layout is shown in Figure 49
Note: The following illustration shows the full segment LCD display for description purposes only
and will not appear like this during normal operation.
