| Operating Instructions Manual | Operating Instructions Manual
15.105:
For a Class B digital device or peripheral, the instructions furnished the user shall include the following or
similar statement, placed in a prominent location in the text of the manual.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC: RSS-GEN
7.1.2 Transmitter Antenna
WARNING: Do not modify this equipment without written authorization of the manufacturer.
Canada Only: This device should be installed and operated in accordance with CAN/CSA-Z386-14:
Laser Safety in Health Care Facilities.
Information in this document is subject to change without notice. User manuals for transmitters shall
display the following notice in a conspicuous location:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approval for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
7.1.3 User Manual
User manuals for license-exempt radio apparatus shall contain the following or equivalent notice in a
conspicuous location in the user manual or alternatively on the device or both.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
[1] this device may not cause interference, and [2] this device must accept any interference, including
interference that may cause undesired operation of the device.
CONTENTS OF PICASSO+ AND PICASSO LITE+
# ITEM DESCRIPTIONS
1 Handle For Transporting the Unit
2
Handpiece & Holder,
Disposable Tip
Multi-Tip Handpiece/Fiber with Fiber Spool, Holder, &
Disposable Tip
3 Emergency Stop Button Disables the Unit In the Event of an Emergency
4 Fiber Spool Stores Fiber
5 Control Panel
Displays & Controls the Parameters (e.g. Power Output,
Presets, Aiming Beam & Intensity, & Speaker Volume)
6 Fiber Connector Port Connects Fiber to the Unit (Laser Aperture)
7 Cooling Vents Cooling Vents
8 Remote Interlock Port Connects optional Remote Interlock to the Unit
9 DC Power Connector Connects Power Supply to the Unit
10 Power Switch Master ON/OFF Switch
11 Key Switch Turns Display of the Unit ON & OFF
12 Quick Start Guide (QSG) Quick Start Guide (QSG)
13 Operating Instructions Manual Operating Instructions Manual
14
Laser Eyewear Protective
Goggles (3)
ANSI Z87, 800–820 nm, Optical Density (OD), includes
Protective Case
15 Unit Keys Used to Turn Machine Off/On
16 Articulating Paper Sample of Paper to Be Used for Laser Tip Initiation
17 Laser Danger Sign Danger Sign for Operatory (Included at End of Manual)
18 AC Adapter
Connects the Unit and Net Power Supply
Input: 100–240 VAC 50/60 Hz, Output: 12VDC, 5A
AC/DC adapter is specified as a part of ME EQUIPMENT
19 Power Cord Power Cord
20 Wireless Foot Control Wireless Foot Control Standard Picasso+ and Picasso Lite+
