SPECIFICATIONS
www.americandynamics.net
Intellex Ultra Intellex DVMS Intellex LT Intellex IP
General
Drive Type Front Access SATA Internal SATA Internal SATA Internal SATA
Exporting CD-RW or DVD-RW CD-RW or DVD-RW
13
CD-RW CD-RW or DVD-RW
Local Archiving (Optional)
External DAT tape (20 GB),
SDLT (160 GB)
External DAT tape (20 GB),
SDLT (160 GB)
N/A N/A
Video Standard NTSC/PAL NTSC/PAL NTSC/PAL N/A
Video Inputs 16 8 (non-looping) or 16 (looping)
4 & 8 (non-looping) or
16 (looping)
Up to 16 network video
streams
Main Monitor Output SVGA, Composite SVGA SVGA SVGA
Analog Output Call/Spot
14
Call/Spot
14
, Live/Play Back
15
Call/Spot
14
, Live/Play Back
15
N/A
Camera Looping Outputs 16 with optional looping panel
Standard on 16-channel
system
Standard on 16-channel
system
N/A
Alarm Inputs and Outputs
16
16 (toolless) 8, 16 4, 8, 16 16 via network device
Single Channel Audio
17
Included Premier Included 5.1 USB adapter included
IEEE 1394 (FireWire) N/A Deluxe, Premier only Included Optional
Network 2x gigabit 1x 100Base-T 1x 100Base-T 2x gigabit
USB (front/back) 2/2 2/4 2/4 2/2
Serial Port (RS-232)
18
1x DB 9 1x DB 9 1x DB 9 1x DB 9
SCSI Interface Optional Optional Optional Optional
Visual Indicators
Power, alarm, record,
disk available, disk activity
Power, alarm, record Power, alarm, record Power, disk activity
Mouse
PC mouse included
as standard
PC mouse included
as standard
PC mouse included
as standard
PC mouse included
as standard
Printer PC printer compatibility
19
PC printer compatibility PC printer compatibility PC printer compatibility
19
Physical
Desktop/Rack Mount
Configurable
Desktop Desktop only Rack Mount only
Dimensions (H x W x D)
130 x 429 x 546 mm
(5.125 x 16.895 x 21.5 in)
172 x 432 x 464 mm
(6.75 x 17.0 x 18.25 in)
172 x 432 x 464 mm
(6.75 x 17.0 x 18.25 in)
43 x 447 x 546 mm
(1.68 x 17.60 x 21.50 in)
Unit Weight 17.3 kg (38 lbs) 14.50 kg (31.90 lbs) 14.50 kg (31.90 lbs) 11.80 kg (26 lbs)
Shipping Weight 25 kg (55 lbs) 16.93 kg (37.25 lbs) 16.93 kg (37.25 lbs) 18.14 kg (40 lbs)
Rack Mount
Dimensions (H x W x D)
175 x 432 x 521 mm
(6.875 x 17.0 x 20.5 in)
Unit Weight 20.39 kg (44.95 lbs)
Shipping Weight 27.24 kg (60.05 lbs)
(13) CD-RW is only available in the Standard and Deluxe Editions; DVD-RW is only available in the Premier Edition.
(14) Call mode displays video from one selected camera in single pane format; spot mode automatically switches from this camera to any alarmed cameras. Available on 16-channel systems only.
(15) Live/Play Back composite output can display the same video as your Intellex monitor or display live video only.
(16) Two part connector—TTL inputs. Open collector outputs.
(17) Jack (3.5 mm).
(18)
On-board serial port recommended for multiplexer control. Additional serial port available in Premier Edition via USB converter.
(19) No parallel port (USB or Ethernet only).
(20) Certification available upon request.
Common Specifications for Intellex Digital Video Management Systems
Environmental Regulatory
20
Operating Temperature 5° to 35°C (41° to 95°F) Emissions FCC 15b, Class B
Humidity 5% to 95% RH (noncondensing) EN55022 (1995) Class A
Storage Conditions -10° to 60°C (14° to 140°F) EN61000-3-2 (1995)
Maximum Operating Altitude 3,048 m (10,000 ft) EN61000-3-3 (1995)
Immunity EN50130-4 (1996)
Electrical
Safety UL 60950-1
Power 100-240 VAC, 50/60 Hz, 3.0/1.5 A EN 60950-1: 2001+A11
Product offerings and specifications are subject to change without notice. Actual products may vary from photos. Not all products include all features. Availability varies by region; contact your sales
representative. Certain product names mentioned herein may be trade names and/or registered trademarks of other companies.
© 2008 Tyco International Ltd. and its respective companies. All rights reserved. AD0005-DS-200805-R07-LT-EN
