STEP
11
7
IMPORTANT! THEBACKPANELISASTRUCTURALPARTOFTHISUNIT
ANDMUSTBEINSTALLEDPROPERLY.
(x34)
#A21110
Withthehelpofanotherperson,turntheunitoveronitsfrontside.Positonbackpanelasshown.
Alignsquarelywithouteredges.Flushbottomedgeofbackpanelwithbottomedgeofthebottom
andnailstraightintobackedgesofleftpanel(A),rightpanel(B),top(C)andbottom(D).
Assurethattheunitissquare.
Distancefromcornertocorner
mustbeequalasshown.

Flushtheedgeofthebackpanel
withthebottomedgeofthe
bottom(D).Alignsquarelyandnail
straightthroughintobackedges.
B
L
D
raw
surface
