Ameriwood 5943220T - Page 10

3
step
10
(2) x4
cam bolt
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.
(13) x1
bracket & screw
(safety bracket kit)
finished edge
C
2
2
2
2
13a
13a
13b
13b
do not tighten screw (13b)
