Ameriwood 5943220T - Step-by-Step Assembly Guide

1
step
8
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.
Proper orientation of CAM LOCK
(1) x2
cam lock
(3)
x2
wood dowel
(11)
x9
#6x7/16" screw
(14)
x3
left cabinet slide
(2)
x2
cam bolt
A
1
1
2
2
3
3
11
11
11
11
11
11
11
11
11
14a
14a
14a
14a
14a
11
2
finished edge
marked with an "L"
