Ameriwood 5947220T - Page 9

2
step
9
Proper orientation of CAM LOCK
11
11
11
B
1
3
1
(1) x2
cam lock
(3)
x1
wood dowel
(11)
x3
#6x
7
16" screw
(13)
x1
right cabinet slide
13b
13b
marked with an "R"
finished edge
1. Refer to page 7 for instructions on how to use the cam lock system.
