Ametek XPD 7.5-67 - Rear Panel Connectors

Section 1. Features and Specifications
Rear Panel Connectors
13
Rear Panel Connectors
Figure 1.2 500 Watt Power Supply Rear Panel (7.5 V and 18 V)
Figure 1.3 500 Watt Power Supply Rear Panel (33 V to 120 V)
Remote Sensing
Port: Remove
Default Jumpers to
use Remote Sensing
Blank Sub-Plate:
Replaced if Digital
Programming
Option is Installed
Fan Exhaust
Vents:
Do not obstruct
Analog
Programming and
Readback
Output Busbars
IEC 320 AC Input
Connector
Busbar Cover
Remote Sensing
Port: Remove
Default Jumpers to
use Remote Sensing
DC Output
Connector:
33 V, 60 V and
120 V models
IEC 320 AC Input
Connector
