MARK 75 BREAD BAGGER
SPECIFICATIONS
ELECTRICAL FEATURES
ELECTRICAL OPTIONS
Throughput Range:
35 - 75 loaves per minute
Electrical Requirements:
Main Power - 7 KVA
Control Power - 24 VDC/120 Volts
Air Requirements - 10 SCFM at 60 PSIG
Loaf Size Range:
Length: 8” (203 mm) 16” (406 mm)
Width: 3-5/8” (98 mm) 5-1/2” (140 mm)
Height: 3” (76 mm) - 6” (152 mm)
Approximate Shipping Weight:
3,400 lb. (1542 kg)
Approximate Dimensions:
104” x 127” x 60”
(2642 mm x 3226 mm x 1524 mm)
• NEMA 12 stainless steel electrical enclosure and
operator console
• Operator panel mounted on a pendant arm
• Missed bag sensor
• Allen Bradley PV 500/600 monochrome/color
touchscreen operator interface in lieu of PV 300
• SLC 5/00 modular hardware programmable logic
controller in lieu of Micrologix 1500
NEMA 12 painted steel operator panel contains the
following:
• Allen Bradley PanelView 300 operator interface
which displays:
- Online timing adjustment
- Status messages
- Precise alarm messages
- Loaf counter
- Speed indicator
• Alarm beacon
• Allen Bradley push buttons for the following
functions:
- Start
- Stop
- Jog
- Manual air blast
- Alarm (acknowledge/reset)
- Emergency stop
NEMA 12 machine mount painted steel electrical
enclosure including:
• Main power disconnect
• Allen Bradley MicroLogix 1500 modular hardware
programmable logic controller
• Allen Bradley Powerflex AC inverter (5 HP) with
brake resistor
• Incremental encoder for scoop position
• Convenience plug installed on panel side to allow
programming without having to open panel door
• 110V outlet and power for tyer and labeler
• Sensor for bag detection
• Double loaf detector
• Safety switch on guards with individual alarm
messages
• Internal lighting
• Recipe management for pre-programmed
specifications for fast bagger set-up
