Trans-axle drive systems
The trans-axle is a precision assembly lubricated for long service. Do not attempt to open or service the
assembly. These actions will void your warranty.
Micro-processing controller (MPC)
Do not attempt to service the MPC or related electronic components as you may void your warranty.
Circuit breaker replacement instructions
An automatic resetting circuit breaker (Figure 9) protects the wiring and batteries
in the event of a short circuit. If the cart stops, check for overloads or short circuits
before continuing to operate. The circuit breaker is located under the rear cover
and attached to the positive terminal on the batteries.
DO NOT CONTINUE TO OPERATE THE CART UNTIL THE CIRCUIT BREAKER IS REPAIRED.
For operation or service questions, call the Amigo service hotline at (989) 777-0910, 8 a.m. to 6 p.m. Monday
through Friday, email service@myamigo.com or visit myamigo.com and click on the chat tab in the bottom right
corner of the page. You can also contact your local service representative. Please reference your serial number
when calling.
Serial number location
There are two serial number locations on each Amigo material handling cart. The Dex™, Dex Pro™ and Dex Pro+™
have one serial number located on the steering column (Figure 10), and another on the bottom of the power base
cover (Figure 11). The Max™ and Max Pro™ have one serial number located on the bottom of the power base cover
(Figure 11), and another on the left side of the handle enclosure, below the throttle (Figure 12). The Dex Pro+
trailer has one serial number located on the rear of the trailer deck (Figure 13).
FIGURE 9
FIGURE 10 (Dex™/Dex Pro™/Dex Pro+™) FIGURE 12 (Max™/Max Pro™)
FIGURE 11 (Dex™/Dex
Pro™/Dex Pro+™ and
Max™/Max Pro™)
(989) 777-0910 9
FIGURE 13 (Dex Pro+™ Trailer)
