#310000 REAR DRIVE PARTS LIST - AMI0063706 TO PRESENT
Part# Description Qty/Unit Part# Description Qty/Unit
24 www.myamigo.com
1025 Bushing w/ Shoulder, 1 1/16 ID x 1 3/16 OD 1
1036 Collar Stem 1
1081 Bushing 1 3/16 OD x 1 Lg 1
1180 Screw, Hex, 1/4-20 x 1 Lg 2
1192 Washer, Flat, 9/32 ID x 5/8 OD 8
1253 Nut, Hex, Keps, 5/16-18 1
1254 Pin, Spring, 1/8 OD x 1 1/8 Lg 1
1299 Seat Lock Asm, RH 1
1344 Screw, Hex, 1/4-20 x 1 1/2 Lg 4
1444 Knob, Arm Adjustment 2
1450 Screw, Hex, 5/16-18 x 2 1/2 Lg 1
2237 Nut, Hex, 3/8-24 1
2788 Seat Lock Asm, LH 1
2822 Screw, Hex, 1/4-20 x 1 3/4 Lg 4
3083 Nut, Hex Serrated Flange, 1/4-20 10
4075 Screw, Flat Head Hex Socket, 1/4-20 x 2 Lg 2
4953 Screw, Hex, 1/4-20 x 2 1/2 Lg 4
5190 Screw, Hex Socket, 1/4-28 x 3/8 Lg 1
5865 Screw, Shoulder, #10-24 x 1 1/4 Lg 2
6191 Post, Lower Seat 1
6227 Nut, Hex, Nylon Insert, #10-24 2
6463 Plug, Round, 7/8" OD 2
6505 Screw, Hex, 3/8-24 x 4 1/2 Lg 1
6993 Bracket, Cord Reel 1
7220 Wire Asm Controller to PSL 1
7281 Screw, Hex Socket, 1/4-20 x 7/8 Lg 2
7361.30 Pot Asm, Health Care 1
7441 Circuit Breaker, Auto Reset, 25 Amp 1
7541 Wheel, Stability, 1 5/8 2
7599 Rivet, Truss Head, 1/4 OD x 1 1/2 Lg 4
7600 Nut, Push, 1/4 Stud 4
7773 Cap, Vinyl Insulated 2
7852 Wire Asm, Charger To Controller, Full Featured 1
7852.10 Wire Asm, Charger To Controller 1
8216 Charger, 3 Amp 1
8221.15 Enclosure, Touch Tron 1
8223.16 Enclosure, Hi/Lo w/ Battery Display 1
8300 Strap, Battery Retaining 1
8417 AC Cord Reel 1
8534 Plug, Tube Square, 1" 2
8669 Tube, Rear Bumper 1
8670 Bracket, Bumper Wheel 2
8675 Ground Wire Asm 1
8694 Bumper Asm Rear 1
8890RD Controller RD 1
8944 Band, Controller and Charger Mounting 4
8969 Cable, MPC Handle Control 1
9005 Power Seat Lift (PSL) 1
9247 Arm Asm, Right, Removable 1
9248 Arm Asm, Left, Removable 1
9250 Arm Asm, Right, 2" Higher Removable 1
9251 Arm Asm, Left, 2" Higher Removable 1
9300RD Controller Full Feature RD 1
9401 Light, Front, High Intensity, Full Featured 1
9699 Seat Asm, Premier I, 18" Gray 1
9766 Wire Asm, Battery To QC 2
9768 Wire Asm, Battery QC To Controller 1
9798 Seat Post Asm, PSL, Upper Accessory Adaptor 1
9855 Arm Asm Set Flip-Up Adjustable Standard 1
9856 Arm Asm Set Flip-Up Adjustable 2" Higher 1
9936 Handle, Upper 1
9950 Lever, Handle Adjustment 1
9967.20 Seat Asm, Premier II, 18" 1
10050 Bearing Set 1
10177 Light, Front, Full Featured 1
10289 Basket, Front 1
10301 Bellows, Cover, Arm Rest 2
10335.20 Column Asm, Red, EZ-Tilt 1
10336.20 Column Asm, Champagne, EZ-Tilt 1
10347.20 Seat Asm, Vinyl, 20" w/ Pouch 1
10511 Fork Weldment, Front 1
10513 Mat, Standard 1
10516 Boot, Lower Handle 1
10539 Light, Front, Hi/Lo 1
10548 Screw, Hex Socket, 1/4-20 x 1 5/8 Lg 4
10554 Clip, Wire Guide 2
10567 Trim, Bumper, RD 1
10571.20 Bracket Asm, Basket 1
10585 Hub Cap, Mag Style Wheel 2
10591 Platform, Standard, Red 1
10594 Platform, Standard, Champagne 1
10595 Platform, Extended, Red 1
10661.20 Seat Asm, Comfortflex I, 18" 1
10662.20 Seat Asm, Comfortflex II, 21" 1
10690 Wheel 9" Front 1
10765.20 Seat Post Asm, Upper Accessory Adapter w/ Knobs 1
10976 Clip, Wire Guide 5
11040 Drive Asm, Standard, 24 V 1
11087 Brake Asm, w/ Microswitch 1
11104 Wheel Asm, 10 Inch 2
11174 Clamp, Motor 2
11236 Motor Asm w/o Brake 1
11264 Bracket Charger/Controller 2
11289 Wire Asm Interface, Controller 1
11311 Washer, Lock, 1/4 ID 4
11355 Screw, Phillips, #6 x 1 1/2 Lg 4
11361.20 Column Asm, Black, EZ-Tilt 1
11364 Platform, Standard, Black 1
11374 Platform, Standard, Blue 1
11381.20 Column Asm, Blue, EZ-Tilt 1
11466 Plate, Back, Standard, Ez Tilt 1
210203 Arm Pad Single Molded 2
210204 Arm Pad Pair Molded 1
267001 Stem Collar Screw & Nut 1
269002 Battery, 12 Volt, 33 AH (U-1) 2
300369 Seat Asm, Premier I, 18" Black 1
300514 Cover Asm, Rear, Black, RD 1
Cover Asm, Rear, Blue, RD
Cover Asm, Rear, Champagne, RD
Cover Asm, Rear, Red, RD
