Front and Rear Panel Descriptions
1. 0 dB Input: Connect a passive instrument to this Input jack.
2. –15 dB Pad: Connect an active instrument to the Input jack.
3. Master: Adjusts the overall input level.
4. EQ: Boost or cut the level at certain frequencies to enhance the sound.
5. Aux Level: Adjusts the Aux Input level.
6. Aux Input: Input for an MP3 player or other music source.
7. Phones Output: Combination playback of the 0 db and -15 dB Inputs, and Aux Input.
8. Power Switch/Power LED: Turns power on or off. The LED indicates power on or off.
9. Power Connector: IEC input socket for power cable.
10. Speaker Output: 1/4" TS output for connecting speaker.
11. Effects Loop: Connect the input and output of an external FX processor.
12. Line Output: Feeds an external mixer or recording device.
13. Speaker Input: 1/4" TS input for connecting to MICRO-CL head.
Getting Started
1. Read and understand the included “Important Safety Instructions.”
2. Make sure the power switch is off before making any connections.
3. Push the line cord securely into the amplifier’s IEC connector and plug the other end into a grounded AC
outlet. The amplifier may accept the appropriate voltage as indicated near the IEC connector.
4. Connect an instrument to the MICRO-CL Input jack with a 1/4" instrument cable. Connect the amplifier to
the to speaker cabinet with a 1/4" TS (non-shielded) speaker cable.
5. With the Level and Master controls fully off, turn on the amplifier by pressing the top edge of the power
switch.
6. While playing the instrument, adjust the Level and Master knobs to the preferred level.
7. Adjust the EQ knobs to taste.
4
