PART DESCRIPTION
AMPEX PART NO. REF. NO.
C502
031-045
C503
033-234
C504
146-057
J502S
146-018
J503S
146-003
J504S
145-012
P505P
043-156
R502
043-002
R503
040-011
R504
R505
6-17
P506P
P507P
R501
P502P
P503P
P504P
C508
C509
C510
C511
J501S
040-007
040-011
145-013
145-013
145-013
020-006
020-006
020-006
145-022
3461-00
567-01
033-008
033-234
033-234
033-005
033-005
033-234
033-234
033-234
146-004
146-003
146-003
120-013
120-004
120-005
5703-03
5782-01
145-022
6582-00
5730-00
120-014
89-0131
89-0144
Issue A
J505S
J 50 6S
K502
K503
K504
P501P
C505
C506
C507
HARNESS ASSEMBLY, Switch
CONNECTOR, Plug: male; 21 contact
SWITCH ASSEMBLY , Safety
SHIELD, Microswitch
SWITCH , Normally closed (STOP)
SWITCH, Normally open (PLAY, FAST FORWARD,
REWIND)
SWITCH, DPST (TAPE SPEED)
SWITCH, SPST (REEL SIZE)
CONTROL BOX ASSEMBLY
CAPACITOR, Fixed: electrolytic; 150 mfd; 150 vdew;
Corncll-Dubilier Part No. 15015
CAPACITOR, Fixed: Mylar; 0.047 mfd; ±10%;
400 vdew; Sprague Type 160P
CAPACITOR, Fixed: paper; 0.25 mfd; ±20%;
400 vdew; Astron Part No. ML-4-25
(Same as C503)
(Same as C503)
CAPACITOR, Fixed: paper; 0.01 mfd; ±20%;
400 vdew; Astron Part No. ML-4-01
(Same as C507)
(Same as C503)
(Same as C503)
(Same as C503)
CONNECTOR, Receptacle: female; 21 contacts;
Jones Part No. S-321-AB
CONNECTOR, Receptacle: female; 10 contacts;
Jones Part No. S-310-AB
CONNECTOR, Receptacle: female; 8 contacts;
Jones Part No. S-308-AB
CONNECTOR, Receptacle: female; 6 contacts;
Jones Part No. S-306-AB
(Same as J503S)
(Same as J503S)
RELAY, 3PDT: 115 vdc coil; 10 amp contacts;
Philtrol Part No. 33QA (PLAY)
(Same as K502) (FAST FORWARD)
(Same as K502) (REWIND)
CONNECTOR, Plug: male; 21 contacts;
Jones Part No. P-321-CCT-L
CONNECTOR, Plug (REMOTE DUMMY PLUG)
CONNECTOR, Plug (60 CYCLE DUMMY PLUG)
CONNECTOR, Plug: male; 6 contacts; Jones Part
No. P-306-CCT-L
CONNECTOR, Plug: male; 8 contacts; Jones Part
No. P-308-CCT-L
(Same as P505P)
(Same as P505P)
RESISTOR, Fixed: wirewound; 10 ohm; ±10%;
5 watt; Tru-Ohm Typo FRL-5
RESISTOR, Fixed: wirewound; 75 ohm; ±5%;
50 watt; Tru-Ohm Type FR-50
RESISTOR, Adjustable: wirewound; 150 ohm; ±5%;
50 watt; Tru-Ohm Type AR-50
RESISTOR, Adjustable: wirewound; 750 ohm; ±5%;
50 watt; Tru-Ohm Typo AR-50
(Same as R503)
