Cleaning of loudspeakers
Clean, dry microfibre cleaning cloth is recommended for the cleaning of Amphion speakers. Difficult to remove dirt or stains
are cleaned by adding a little water to the towel and using mild soap water- solution if needed. Before using any stronger
detergents you should test these first to the bottom of the speaker to ensure it does no damage the surface of speaker.
Fault situations
All Amphion products are always measured, tested and checked by skilled craftsmen before they leave from factory. However,
if some malfunction occurs, speakers should be returned to the authorized dealer where they were bought from
.
The most common fault situation is caused by improper cable connections. Make sure that cabling and connections are properly
done. If one speaker is silent you can change that speaker to another channel which works. If speaker works after the switch the
problem lies elsewhere in the signal chain. If the speaker still remains silent it is possibly damaged.
Warranty
Warranty of the speakers is 5 years from the day of purchase. The warranty covers all faults related to manufacturing and
materials. Warranty does not cover faults caused by misapplication or mistreating of speaker. The most common misapplication
is damage for tweeter-unit caused by too high listening levels. The bass unit can be also damaged when too high listening
levels are used.
If the sound is distorting the level of volume should be lowered immediately. Warranty does not cover damages caused by
too high listening levels.
The disassembling of speaker units, connector panel or any other part of speaker causes warranty to be void. The grid of bass
unit is meant to be permanently mounted and should not be removed.
Technical specifications
Operation principle: 2-way vented
Tweeter: 1”
Bass: 4½”
Crossover frequency: 1600 Hz
Impedance: 8 ohm
Sensitivity: 86 dB
Frequency response: 55 – 20 000 Hz, -6dB
Recommended power: 20 – 120 W
Dimensions (h x w x d): 10½” x 5¼” x 8¾”
(268 x 134 x 220 mm)
Cabinet material: Painted ¾”, (19mm)MDF
Weight: 10½ lbs. (4,7 kg) per piece
Amphion Loudspeakers Ltd.
PL 6, 70821 Kuopio, Finland
www.amphion.fi
Picture 2. Position the speakers symmetrically
Picture 1. The acoustical centre point of the speaker is
in the middle of waveguide and bass-unit.
