Recommended Enclosures
Please note that all enclosure volumes include displacement for speaker
and port. Do not add to these measurements. Sealed and ported enclo-
sures, as well as the sealed chamber (Vb1) on all bandpass enclosures
should be lined on 3 walls with 1.75” to 2.5” thick Dacron or Pollyfill
material. The ported (Vb2) chamber on all bandpass enclosures can be
lined on 1 or 2 walls. Do not restrict any port area with filler.
ACWD
“Performance”
Series DVC Subwoofers
SEALED VENTED BANDPASS
1000 cu. ft Vb1 .65 1.125 Sealed .55
cu. ft Vb2 Ported .69
Port (qty.) DxL (1) 3”x 10.5” (1) 4”x 11”
Fb Tunning Freq. 37Hz 60Hz
1200 cu. ft Vb1 1.25 1.75 Sealed 1.0
cu. ft Vb2 Ported 1.5
Port (qty.) DxL (1) 4”x11” (1) 6”x10.7”
Fb Tunning Freq. 38Hz 59Hz
1500 cu. ft Vb1 1.75 2.70 Sealed 1.95
cu. ft Vb2 Ported 2.00
Port (qty.) DxL (1) 4”x7” (1) 6”x5”
Fb Tunning Freq. 35Hz 60Hz
Exonic
“Competition”
Series DVC Subwoofers
SEALED VENTED BANDPASS
1000 cu. ft Vb1 .65 1.125 Sealed .55
cu. ft Vb2 Ported .63
Port (qty.) DxL (1) 3”x 10.5” (1) 4”x12”
Fb Tunning Freq. 37Hz 60Hz
1200 cu. ft Vb1 1.12 1.75 Sealed 1.0
cu. ft Vb2 Ported 1.5
Port (qty.) DxL (1) 4”x11” (1) 6”x9.50”
Fb Tunning Freq. 38Hz 59Hz
1500 cu. ft Vb1 1.65 2.70 Sealed 1.95
cu. ft Vb2 Ported 2.00
Port (qty.) DxL (1) 4”x7” (1) 6”x5”
Fb Tunning Freq. 35Hz 57Hz
3
Subwoofer Parameters
SERIES ACWD EXONIC EXONIC
MODEL 1000 1200 1500 1000 1200 1500 10X 12X
Fs (Hz) 27.9 27.6 20.8 32.3 24.3 21.3 31.5 25.6
BWs (Hz) 14.2 13.7 13.3 17.0 15.3 12.8 15.2 13.0
Qms 6.80 8.02 7.07 8.53 7.63 7.95 12.8 13.2
Qes. 0.48 0.54 0.36 0.45 0.34 0.37 0.34 0.30
Qts 0.45 0.51 0.35 0.42 0.33 0.35 0.33 0.30
Zmaxs (ohms) 25.5 26.9 34.7 34.2 39.6 38.7 65.1 75.3
Vas (Liters) 51.5 89.4 304 38.4 112 294 17.8 44.1
Xmax (mm) 5.7 5.7 5.7 5.7 5.7 5.7 13.2 13.2
Pwr. (RMS) 200 250 300 300 350 400 800 1000
Pwr. (Max) 400 500 600 600 700 800 1600 2000
Sens. dB1w/1m 85.5 87.3 90.6 86.4 88.5 90.8 83.9 85.7
Displacement (ft3) .07 .11 .197 .075 .11 .21 .12 .17
Impedance Dual 4ohm Dual 4ohm Dual 4ohm
