MIO-CLASSIC-S (FG5795-01XX)/
MIO-CLASSIC-D (FG5795-02XX)
POWER
10-18 vDC
12V CURRENT DRAW
• Eight Button Single Style = 77.5mA Nominal - 140.3mA Maximum
• Sixteen Button Double Style = 133.8mA Nominal - 244.6mA
Maximum
FRONT PANEL COMPONENTS
• Pushbuttons - a maximum of 8 buttons on the single style and 16
buttons on the double style. The Classic provides a direct LED light.
• Red LEDs indicate activity.
REAR PANEL COMPONENTS
• DIP switch - 8 position mini DIP switch used to set the device address
for the keypad on the AXlink Bus.
• Wiring connection - 4 pin 3.5mm Phoenix AXlink connector.
DIMENSIONS (HWD)
• Single style - 4.46" x 2.71" x .57" (113.28 mm x 68.83 mm
x 14.48 mm)
• Double style - 4.46" x 4.39" x .57" (113.28 mm x 111.51 mm
x 14.48 mm)
SUPPORTED LANGUAGES
• English
• Spanish
• French
• Italian
• German
• Portuguese
• Arabic
• Mandarin Chinese
• Russian
• Japanese
• Thai
• Hindi
• Korean
• Greek
WEIGHT (RANGE)
.25 lbs (.11 kg) - .50 lbs (.23 kg)
OPERATING ENVIRONMENT
• Operating Temperature: 0° to 50° C (32° to 122° F)
• Storage Temperature: -10° to 70° C (14° to 158° F)
MOUNTING
Mounts into US and a majority of International single gang back boxes.
INCLUDED ACCESSORIES
• Single style mounting kit
• Double style mounting kit
OPTIONAL ACCESSORIES
• Additional custom buttons (FG5795-21XX - Set of 4 Custom Single
Buttons, FG5795-22XX - Set of 2 Custom Double Buttons)
• Blank button kits (FG5795-07XX)
• International extension plates (for some larger wallboxes)
mio modero classic
ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
10.2005 © 2005 AMX Corporation. All rights reserved. AMX and the AMX logo are all trademarks of AMX Corporation. AMX reserves the right to alter specifications without notice at any time.
