Installation
13
MST-431/MSD-431-L 4.3" Modero S Series® Touch Panels
Installation
MST-431 Installation
Any USB peripherals (mouse, keyboard, etc.) may be connected to the USB port on the rear of the device
(FIG. 8). Updates to the device’s firmware are also made via the USB port..
Power via Power Over Ethernet
Power for the MST-431 is supplied via Power Over Ethernet (PoE), utilizing an AMX-certified, capacitive
touch-compliant PoE injector such as the PS-POE-AT High Power PoE Injector (FG423-81) or other approved
AMX PoE power source. The incoming Ethernet cable should be connected to the RJ45 port on the device
(FIG. 8).
FIG. 8 Connectors on the rear of the MST-431
USB Port
Entry for RJ45/
PoE Cable
Speaker
