GENERAL
AC Power: 100-240 VAC single phase, 50-60 Hz
Power Consumption (max): 60 Watts per enclosure
Operational Temperature: 32° to 110° F (0° to 43° C)
Humidity: 0 to 90% non-condensing
Enclosure Dimensions: 10.4” (26.40 cm) depth
17.4” (44.2 cm) width without rack ears
19.0“ (48.26 cm) width with rack ears
Height: 3.5” (8.89 cm) height 2 RU
Weight: Appx. 10.5 lb (4.76 kg) per enclosure
Approvals: UL, CUL, CE
COMPONENT & STEREO
STANDARD AUDIO
Input Level (max): +14 dBu, unbalanced (RCA)
+14 dBu, balanced (5T)
Input Impedance: 18 kΩ
Output Level (max): +14 dBu, unbalanced (RCA)
+14 dBu, balanced (5T)
Output Impedance: 50 Ω
Frequency Response: <+/-0.1 dB (20 Hz to 20 kHz)
THD + Noise: <0.025% (20 Hz to 20 kHz, Vin = -10 to +14 dBu)
Signal to Noise Ratio: >105 dB (20 Hz to 20 kHz, Vin = +14 dBu)
Crosstalk: <-105 dB (1 kHz, Vin = +2 dBu)
Connectors: 5T or RCA
WIDEBAND VIDEO
Input Level (max): +/-1.5 Volts
Input Impedance: 75 Ω
Output Level (max): +/-1.5 Volts
Output Impedance: 75 Ω
Frequency Response: 300 MHz or better (+/-3 dB)
100 MHz or better (+/-1.5 dB)
Crosstalk: <-70 dB (f = 5 MHz)
<-35 dB (f = 150 MHz)
Signal to Noise Ratio: >65 dB (Vin = 0.7 V, 100% IRE)
Differential Gain: < 0.2% or better (f = 3.58 MHz)
Differential Phase: < 0.2° or better (f = 3.58 MHz)
Connectors: BNC or RCA
PRECIS LT DATA SHEET
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
3 COMPONENT + STEREO (RCA/RCA)
Available: 4x4, 4x8, 8x4, 8x8
AVS-PL-0808-A43
(FGP37-0808-A43)
3 COMPONENT + STEREO (BNC/5T)
Available: 4x4, 4x8, 8x4, 8x8
AVS-PL-0808-345
(FGP37-0808-345)
