NOTE: You can also access the audio outputs setup page via the A/V Mapping tab.
4. Under Audio Outputs (middle window), enable/disable the Link button if required to link/unlink
channel pairs:
• Enable Link to link channel pairs and use the first channel pair settings for all pairs.
• Disable Link to unlink channel pairs and set up channel pairs individually.
5. Locate the channel pair to adjust if required.
NOTE: If channel pairs are linked, only the first channel pair settings are available.
6. Click and drag the Volume control bar to adjust the volume of the channel pair.
Remember: If channel pairs are linked, the first channel pair setting will be used for all pairs.
TIP: Click on the Headphone button if required (located under the input) to prelisten to the selected audio pair on
the headphone output.
