AndyMark AM14U4 - Power Train and Wheel Configuration; Wheel Overview

4
Power Train Specifications
The AM14U4 Kit of Parts Chassis Base Kit includes Gates HTD belts and the parts needed to build a 6” 6-wheel drive
chassis with a direct drive center wheel in three recommended frame sizes. Other belt sizes are available on
AndyMark.com or through Gates to allow for many more configurations.
Additionally, the AM14U4 parts can be used in other popular drive configurations as well. Sprocket & Chain, Direct
Drive Mecanum Wheels, and 8WD can all be built by using the frame in this kit and swapping out some of the parts.
For details on how to change your drive system visit AndyMark.com/AM14u4
Wheel Overview
Included in the Drive Base Kit are 6” 80A HiGrip Wheels. These wheels are made of high-strength polycarbonate with
an 80A urethane tread. These wheels provide long-lasting grip throughout the competition season. Many other
wheels can be used as an alternative with minor adjustments to the plate spacing and layout.
6” HiGrip Wheels
am-0940b
INCLUDED
INCLUDED
120, 131, and 160 Tooth Gates Belts for 3 recommended sizes
OPTIONAL
Mecanum Drive
8-Wheel Drive
OPTIONAL
DuraOmni Wheels
am-3154
Performance Wheels
am-0095b
SmoothGrip Wheels
am-0144a
Plus many other 4”,
6”, and 8” options.
For full information
please visit
AndyMark.com
