By turning the switch to the "O" position, the motor will immediately stop, ”O”
and ”I” are displayed on the switch button.
Position:
behind and to the left of the rear handle.
(d).
Operate the primer
Pull out the primer button to close it; press it to open it.
Position:
r behind and to the left of the rear handle.
(e).
Oil pump adjustment
If you turn the rod clockwise with a screwdriver, the oil flow
flows more, and if you turn it counter-clockwise, less.
Position:
Bottom of the rear handle.
(f).
The screw under the “H” seal is the high speed mix adjusting
screw.
.
The screw under the "L" is the low speed adjusting screw.
The screw on the "T" is the idle adjustment screw.
Position: above and to the left of the rear handle
(g).
Shows the directions in which the chain brake is released
(white arrow) and engaged (black arrow).
Position: Front Handlebar
(h).
Shows the installation direction of the chain saw.
Position: In front of the chain cover
(I). Sound level of this equipment.
MG246:113 dB (A)
MG252: 114 dB (A)
(J). Manual engine start.
k) Decompression valve (if included)
Press the button on the decompression valve to open it.
