4-6 RF Calibrator 50 MHz Frequency (ML248xx without Option 15) Chapter 4 — Adjustment
4-4 PN: 13000-00164 Rev. K ML248xx, ML249xA MM
4-6 RF Calibrator 50 MHz Frequency (ML248xx without Option 15)
(If the power meter is a ML2495/6A or ML248xx fitted with option 15 (1 GHz reference), go to Section 4-8.)
To calibrate the 50 MHz frequency of the reference:
1. Connect an RF frequency cable from the power meter RF calibrator output to an Anritsu MF2412B
frequency counter.
2. Set the RF calibrator to ON at 0 dBm by pressing the front panel keys as follows:
Cal/Zero | Calibrator | Calibrator RF
A bright green indicator is displayed in the button when the calibrator is switched on.
3. Adjust inductor core L12 with a non-metal adjustment tool for a frequency reading of 50 MHz ±500 kHz.
See Figure 4-1 for inductor location.
4. Disconnect the frequency counter from the power meter.
5. Record results and calculations in Section 4-6: RF Calibrator 50 MHz Frequency Adjustment (ML248xx
without Option 15) of Appendix A.
4-7 RF Calibrator Output Power (ML248xx without Option 15)
To adjust the RF Calibrator output power:
1. If the reference calibrator output power level is outside of the 1 mW ±0.0015 mW limits, adjust R82 and
recalculate P
actual
Upper and P
actual
Lower with the new V
0
,V
1
,andV
comp
numbers using the same
equations as in Section 3-7 of Chapter 3.
2. Repeat Step 1 until P
actual
Upper and P
actual
Lower are both within specification.
3. Record results and calculations in Section 4-7: RF Calibrator Output Power Adjustment (ML248xx
without Option 15) of Appendix A.
4-8 RF Calibrator 50 MHz Frequency and 50 MHz/1 GHz Output Power
Use the following steps to adjust and set the 50 MHz frequency and 50 MHz / 1 GHz Output Power Level on an
ML249xA or an ML248xx with option 15 installed. The values are entered into an EPROM on the calibrator
board and stored.
Required Equipment
• Frequency Counter: Anritsu MF2412B
• Power Meter: Agilent 432A
• Power Sensor: Agilent 8478B
• Voltmeter: Agilent 34420A Nano Volt, Micro-Ohm Meter
Preliminary Steps
1. Connect RF cable from calibrator to front panel of the MF2412B frequency counter.
2. Connect a GPIB cable from the PC to the unit under test.
3. Apply AC power to power meter and turn on.
4. Open Measurement & Automation Explorer on the PC desk top icon.
5. Navigate to GPIBO (PCI-GPIB) and search for Instrument0 as shown in Figure 4-2.
Note
If a metal adjustment tool is used, it must be removed from inductor L12 before reading the counter,
as the metal tool may affect the frequency.
