MS2721B MM PN: 10580-00177 Rev. D A-35
Option 44 WCDMA and HSDPA RF Measurements (continued)
Option 45 WCDMA Demodulator and Option 65 WCDMA/HSDPA Demodulator
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-105.WCDMA ACLR Accuracy, Option 44
Frequency/Offset Measured ACLR Calculated ACLR Error Specification
881.5/–10 MHz dB dB ± 0.8 dB
881.5/–5 MHz dB dB ± 0.8 dB
881.5/+5 MHz dB dB ± 0.8 dB
881.5/+10 MHz dB dB ± 0.8 dB
1962.5/–10 MHz dB dB ± 0.8 dB
1962.5/–5 MHz dB dB ± 0.8 dB
1962.5/+5 MHz dB dB ± 0.8 dB
1962.5/+10 MHz dB dB ± 0.8 dB
2680.5/–10 MHz dB dB ± 0.8 dB
2680.5/–5 MHz dB dB ± 0.8 dB
2680.5/+5 MHz dB dB ± 0.8 dB
2680.5/+10 MHz dB dB ± 0.8 dB
Table A-106.HSDPA RF Channel Power Accuracy, Option 44
Frequency Power Meter Reading Measured RF Channel Power
RF Channel
Power Accuracy Specification
2680.5 MHz dBm dBm dB ± 1.25 dB
Table A-107.HSDPA ACLR Accuracy, Option 44
Frequency/Offset Measured ACLR Calculated ACLR Error Specification
2680.5/–10 MHz dB dB ± 1.0 dB
2680.5/–5 MHz dB dB ± 1.0 dB
2680.5/+5 MHz dB dB ± 1.0 dB
2680.5/+10 MHz dB dB ± 1.0 dB
Table A-108.WCDMA Error Vector Magnitude (Test Model 4; Option 45 or Option 65)
Frequency EVM Specification
1962.5 MHz %±2.5%
Table A-109.HSDPA Error Vector Magnitude (Test Model 5; Option 65)
Frequency EVM Specification
1962.5 MHz %±2.5%
