21
2.
15
b
| EINBAU
RADIO
TRAY
2.
15
b
| RADIO
TRAY ASSEMBLY
Flat head self taping screw 3x10
Round head selftaping screw 3x12
Philips head machined screw M3x12
1x
1x
7x
Round head machined screw M3x15
1x
(M3x15)
(3x10)
(3x12)
4150-0001_manual_virus3_kit_12-08.indd 21
05.09.12 14:46
20
22
