Ansul INERGEN User Manual

Form No. Pages
I. COMPONENTS 1-1 – 1-33
CV-98 CYLINDER SHIPPING ASSEMBLY F-2001249 1-1
AUTOPULSE
® CONTROL SYSTEM F-2001250 1-2
ANSUL AUTOMAN
®
II-C RELEASING DEVICE F-2001251 1-3
SELECTOR VALVES F-2001252-1 1-4
PRESSURE OPERATED STACKABLE ACTUATOR F-2001253 1-5
BOOSTER ACTUATOR F-2001254 1-6
HF ELECTRIC ACTUATOR F-2001255 1-7
LEVER RELEASE ACTUATOR F-2001256-1 1-8
MANUAL PULL BOX F-2001257 1-9
CABLE WITH SWAGED END FITTING F-2001258 1-10
CORNER PULLEY F-2001259 1-11
DUAL/TRIPLE CONTROL BOXES F-2001260 1-12
REMOTE CABLE PULL EQUALIZER F-2001261 1-13
PRESSURE BLEEDER PLUG – 1/4 IN. F-2001262 1-14
FLEXIBLE DISCHARGE BEND F-2001263 1-15
CHECK VALVES F-2001264 1-16
HEADER VENT PLUG F-2001265 1-17
STAINLESS STEEL ACTUATION HOSE F-2001266 1-18
PRESSURE REDUCER/UNION F-2001267 1-19
FLANGED PRESSURE REDUCER F-2001269 1-20
DISCHARGE NOZZLE – 360° F-2001272 1-21
180° DISCHARGE NOZZLE F-2001273 1-22
NOZZLE DEFLECTOR SHIELD F-2001274 1-23
CYLINDER BRACKETING F-2001275-1 1-24
PRESSURE SWITCH – DPST F-2001276 1-25
PRESSURE SWITCH – DPDT-EXPLOSION-PROOF F-2001277 1-26
PRESSURE SWITCH – 3PST F-2001278 1-27
PRESSURE TRIP F-2001279 1-28
PRESSURE TEST ASSEMBLY F-2001280 1-29
NAMEPLATE – MAIN F-2001283 1-30
NAMEPLATE – RESERVE F-2001284 1-31
WARNING PLATE – INSIDE ROOM WITH ALARM F-2001285 1-32
WARNING PLATE – OUTSIDE ROOM WITHOUT ALARM F-2001286 1-33
II. SPECIFICATIONS
SYSTEM SPECIFICATION SHEET F-2001292-1
AGENT SPECIFICATION SHEET F-200045-1
MSDS F-9759-2
Table of Contents
7-15-02 REV. 1
Page 1
ANSUL
®
®

Ansul INERGEN Specifications

General

Agent	INERGEN
Components	Nitrogen, Argon, Carbon Dioxide
Agent Composition	52% Nitrogen, 40% Argon, 8% Carbon Dioxide
Storage	High-pressure cylinders
Cylinder Material	Steel
Application	Total flooding fire suppression
Design Concentration	34.2% - 50% (depending on fuel type)
Storage Pressure	3000 psi (207 bar)
Environmental Impact	Zero ozone depletion potential, no global warming potential
Safety	Safe for use in occupied spaces when design concentration is maintained
Extinguishing Mechanism	Oxygen reduction to below combustion level
Approvals	UL, FM
Cylinder Sizes	Various sizes
Discharge Time	Typically less than 60 seconds
Typical Applications	Data centers, telecommunications, museums, archives
