LED display
8-2
NS_R
Network
Status LED
Red
Red
ON
Fatal error
 System error
 Watchdog timer error
 Memory error
Flashing
(single flash)
Station name error
Flashing
(Double flashes)
IP address error
Flashing
(Triple flashes)
Configuration error
OFF
Offline
 Power supply is OFF.
Link/Activity
PROFINET
Link status
indicator
Green
ON
No link detection/traffic detection
Flashing
Link detection/traffic detection
OFF
Not linked
