26
Panel
Model name 24E2D
Driving system TFT Color LCD
Viewable Image Size 60.47cm diagonal
Pixel pitch 0.2745(H)mm x 0.2745(V) mm
Video R, G, B Analog Interface & DVI Interface
Separate Sync H/V TTL
Display Color 16.7M Colors
Others
Horizontal scan range
30-85kHz
Horizontal scan Size(Maximum) 527.04mm
Vertical scan range 48-75Hz
Vertical Scan Size(Maximum) 296.46mm
Optimal preset resolution 1920x1080@60Hz
Max resolution 1920x1080@60Hz
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz
Power Consumption
Typical(default brightness and contrast) 20W
Max. (brightness = 100, contrast =100) ≤ 22W
Standby mode ≤0.3W
Physical
Characteristics
Connector Type DVI/D-Sub
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
