AOC 24P2Q User Manual

26
Panel
Model name 27P2Q
Driving system TFT Color LCD
Viewable Image Size 68.60cm diagonal
Pixel pitch 0.3114 (H)mm x 0.3114(V) mm
Video
R, G, B Analog Interface & HDMI Interface & DP Interface&
DVI Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Others
Horizontal scan range 30~85kHz
Horizontal scan Size(Maximum) 597.888mm
Vertical scan range 48~75Hz
Vertical Scan Size(Maximum) 336.312mm
Optimal preset resolution 1920x1080@60Hz
Max resolution
1920x1080@60Hz(VGA/DVI)
1920x1080@75Hz(HDMI/DP)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz
Power Consumption
Typical(default brightness and contrast)
20
W
Max. (brightness = 100, contrast =100) ≤
60W
Power saving ≤0.5W
Physical
Characteristics
Connector Type
DP/DVI/HDMI/D-Sub/Audio in/Earphone out/USB3.2 Gen1x4
(includes 1 fast charger)
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )

AOC 24P2Q Specifications

General

Brand	AOC
Model	24P2Q
Category	Monitor
Language	English
