7
3.3 Compatible Mode Table
Analog RGB Input Signal Timing
D26W931/D32W931/LC42H053
Dots × Lines
Horizontal Vertical Sync Polarity Presence Screen Mode
Frequency Frequency
Horizontal Vertical Horizontal Vertical
Normal
(4:3)
Full
(16:9)
(kHz) (Hz)
720×400 31.47 70.00
NEG POS YES YES YES YES
640×480 31.47 59.94
NEG NEG YES YES YES YES
640×480 37.50 75.00
NEG NEG YES YES YES YES
640×480 37.86 72.81
NEG NEG YES YES YES YES
800×600 37.88 60.32
POS POS YES YES YES YES
800×600 46.88 75.00
POS POS YES YES YES YES
800×600 48.08 72.19
POS POS YES YES YES YES
832×624 49.73 74.55
NEG NEG YES YES YES YES
1024×768 48.40 60.00
NEG NEG YES YES YES YES
1024×768 60.02 75.03
POS POS YES YES YES YES
1024×768 56.48 70.07
NEG NEG YES YES YES YES
1360×768 47.70 60.00
POS POS YES YES YES YES
LC32W053
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
VGA
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
640x480@75Hz 840 x 500 37.5 N 75 N 31.500
720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
SVGA
800x600@56Hz 1024 x 625 35.156 P 56.25 P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.097 P 72.188 P 40.000
800x600@75Hz 1056 x 625 46.875 P 75 P 49.5
XGA
1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328x806 56.476 N 70.069 N 75.000
1024x768@75Hz 1312x800 60.023 P 75.029 P 78.750
WXGA 1360x768@60Hz 1792X795 47.712 P 60.015 P 85.5
