4.3.3 Electrical Characteristics
Parameter Symbol
Values
Unit Notes
Min Typ Max
MODULE :
Power Supply Input Voltage VLCD 4.5 5.0 5.5 Vdc
Permissive Power Input Ripple VLCD - - 0.3 V 1
Power Supply Input Current ILCD
60Hz - 940 1220 mA
2
75Hz - - 1310 mA
60Hz - 1110 1450 mA
3
75Hz - - 1560 mA
Power Consumption
PLCD_TYP
(@60Hz)
- 4.7 6.1 Watt 2
PLCD_MAX
(@60Hz)
- 5.5 7.2 Watt 3
Inrush current IRUSH - - 3.5 A 4
LED bar Electrical characteristics
Parameter Symbol
Values
Unit Notes
Min. Typ. Max.
LED String Current Is - 100 110 mA 1, 2, 5
LED String Voltage Vs 43.5 46.5 49.5 V 1, 5
Power Consumption PBar - 14.0 14.9 Watt 1, 2, 4
LED Life Time LED_LT 30,000 - - Hrs 3
