AOC I2267FWH User Manual

48
C204,C205,C207,C208,C
210,C211,C216,C217,C2
18,C219,C87
C52,C53 0CH2A-0023A
0.1U F, 25 Volt, K PER, X7R(JB), 1608
R/TP, T=0.9(MAX)
C51 0CH2A-0027A 1uF, K, 16V, X7R, 0.9mm, 1608, R/TP
C21,C22,C220,C221,C22
2,C223,C224,C24,C25,C2
6,C27
0CH2A-0030A 1uF, K, 10V, X5R, 0.55mm, 1005, R/TP
C105 0CH2A-0038A
0.1U F, 25 Volt, Z PER, Y5V(JF), 1005
R/TP, T0.55(MAX)
C215,C80,C94 0CH2A-0040A 10uF, K, 10V, X5R, 0.95mm, 2012, R/TP
C20,C23 0CH2A-0068A
10 Volt, X7R(JB), K %, 1005 R/TP, 0.1U
F, T=0.55 MAX
C71,C72 0CH2A-0069A
MLCC ** 10uf，
K,16V,X5R,1.35mm,2012,R/TP
C2,C3 0CH2A-0072A
MLCC ** 10uf，
K,10V,X5R,1.35mm,2012,R/TP
C120,C121,C82 0CH2A-0088A 3.3nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C109 0CH5330K412 33PF, J, 50V, 1608, R/TP, 0.9mm
D3,D6 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
D1 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
D2 0DHZL-0131A SDB0740, AUK, SOT-23, R/TP
ZD1 0DHZL-0138A KDZ8.2V, KEC, USC, R/TP
F1 0FSLO-0013A F0603HI3000V032T, AEM, Ceramic
U2 0IDHL-0014A
DB1510BNN2TR33, DONGBU HITEK,
FIX_3.3V, 1A, SOT-223, R/TP,
U1 0IROL-0036A
BR24T04FVT, ROHM, 4K, 5MS,
TSSOP-B8, R/TP, 8
US1 0ISML-0019A
SM4041, SILICON MITUS, MNT, VDD
BOOST + VGH BOOST + VCC BUCK +
L/S + OPAMP + DISCHARGING + GPM
+ PVCOM, QFN, R/TP, 48
UC1 0ITLL-0064A
TL2349EP, TLI, LVDS, 6/8, 2, EPI, 6, 4,
DRD, SGIP, AFRC, DGA, SD, SM, SFA,
L80, LOWELL, MLF, TR, 48
L1 0LCAA-0069B
TNI8016-100M, DACOWELL, 10UH,
M=20%, 2.1A, 0.093, 8.0X11.0X1.8
(1.2MM, IN-BOARD), R/TP
L2,L3 0LCAA-0089A
CMI-DOP3910NH-6R8M, COIL
MASTER, 6.8 UH, M=20%, 0.9 A, 0.26
