Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
1.
Pow
e
r
3. DVI port
To protect equipment, always turn off the PC and LCD monitor before connecting.
1 Connect the power cable to the AC port on the back of the monitor.
2 Connect one end of the 15-pin D-Sub/DVI port to the back of the monitor and connect the other end to the
computer's D-Sub/DVI.
3 Turn on your monitor and computer.
If your monitor displays an image, installation is complete. If it does not display an image, please refer
Troubleshooting.
2.
D-Sub port
21
3
3
DVI
I2269V
W
/I2369V
/I2769V
