No. Description P/N QTY

1 Bezel A34G3198AEDA1B0130 1

2 Power_lens A33G1429--1-1C0100 1

3 Key_button A33G1437AED-1B0100 1

4 Middle_frame A34G3199AED-1B0100 1

5 mylar_btm Q52G1801MNT176 1

6 mylar_top Q52G1801MNT177 1

7 Main_frame Q15G1351801 1

8 Vesa bkt P15G8299--3 1

9 Rear_cover A34G3200AED-3B0130 1

10 Stand_front A34G3202AED-1B0100 1

11 hinge Q37G0307012 1

12 Stand_rear A33G1451AED-1B0100 1

13 Hinge_cover A34G3203AED-1B0100 1

14 Base A34G3201AED-1B0130 1

15 Base_bkt Q15G1406101 1

16 FOOT PAD Q12G6082--1 5

S1 MAIN FRAME TO PANEL(BACK SIDE) 0M1G3030--4120 1

S2 SCALER TO MAINFRAME(1A2H1DP) 0D1G1030--6120 2

S3 POWER TO MIANFRAME 0D1G1030--6120 2

S4 POWER TO MIANFRAME 0M1G1140--6120 1

S5 MIDDLE FRAME TO PANEL 0M1G3030--4120 8

S6 HINGE TO REAR COVER AM1G1740-10225-CR3 4

S7 REAR COVER TO MAIN FRAME 0M1G3030--4120 2

S8 BKT BASE TO BASE 0Q1G-930--8120 2

S9 HAND SCREW Q01G700100A003 1

S10 REAR COVER TO PANEL 0Q1G-930--8120 1
