AOC i2769Vm Service Manual

57
SOP-8 MXIC
Q405,Q501,Q503,Q505,Q
601,Q702
057G-417511
TRA MMBT3904 0.2A/40V SOT-23 BLUE
ROCKET
057G-417518
TRA LMBT3904LT1G 0.2A/40V SOT-23
LRC
2nd source
Q401,Q402,Q504,Q602 057G-417512
TRA MMBT3906 0.2A/40V SOT-23 BLUE
ROCKET
057G-417517
TRA LMBT3906LT1G -0.2A/-40V SOT-23
LRC
2nd source
Q502,Q506 057G-759-2A-HF MOSFET 2N7002H SOT-23 Panjit
057G-759-2A MOSFET 2N7002 0.2A/60V SOT-23 Panjit 2nd source
Q403 057G-763940 MOSFET AO3401A 4.2A/30V SOT-23 AOS
R177,R179,R180,R181,R
182,R406,R407,R417,R4
23,R441,R442,R502,R50
3,R504,R505,R506,R507,
R508,R509,R521,R522,R
523,R524,R525,R526,R5
27,R529,R552,R614
061G0402000-JI
TEST ONLY RST 0402 0.05R MAX 1/16W
TA-I
061G0402000-JY RST CHIPR 0 OHM -5% 1/16W YAGEO 2nd source
R103,R109,R115,R515,R
536,R651,R652,R653,R6
54
061G0402100-JY
RST CHIPR 10 OHM +-5% 1/16W 0402
YAGEO
061G0402100-JT
RST CHIPR 10 OHM -5% 1/16W 0402
TZAI YUAN
2nd source
R619 061G04021001FY RST CHIPR 1KOHM 1% 1/16W YAGEO
R112,R119,R120,R188,R
192,R424,R429,R432,R4
33,R434,R501,R528,R54
2,R550,R603,R606,R649,
R704
061G0402101-JY
RST CHIPR 100 OHM +-5% 1/16W 0402
YAGEO
061G0402101-JT
RST CHIPR 100 OHM -5% 1/16W 0402
TZAI YUAN
2nd source
R178,R411,R412,R413,R
485,R486,R511,R551,R6
20,R621,R622
061G0402102-JY
RST CHIPR 1 KOHM +-5% 1/16W 0402
YAGEO
061G0402102-JT
RST CHIPR 1 KOHM -5% 1/16W 0402
TZAI YUAN
2nd source
R470,R471 061G04021021FT RST 0402 1.02K 1% 1/16W TZAI YUAN
R401,R403,R404,R425,R
479,R520,R541,R547,R6
061G0402103-JI
RST CHIPR 10 KOHM +-5% 1/16W 0402
TA-I
