AOC i2769Vm Service Manual

69
061G-17222052T--XZ
RST CFR 22 OHM -5% 1/4W
XIANZHENG
2nd source
R906 061G152M10452T--SY MOFR 100KOHM +-5% 2WS SHUANGYU
R904 061G152M25152T--SY RST MOFR 250 OHM +-5% 2WS FUTABA
R924 061G152M43852T--SY RST MOFR 0.43 OHM +-5% 2WS FUTABA
061G152M43852T--HX RST MOF 0.43R 5% 2WS HX 2nd source
C911 065G--2K152-2T6921 CAP CER 1500pF K 2KV Y5P
065G--2K152-2T6213 CAP CER 1500PF K 2KV 2nd source
C805 065G500K4742HT CAP CER 470NF 10% 50V X7R TORCH
C816 065G517K102-2T6921
CAP CER 1000pF +-10% 500V Y5P
WANSHENG
C920 067G-2041022LT EC 1000uF 20% 10V 10*12 2000Hr LELON
067G-2041022KT
EC 1000uF 20% 10V 10*12 2000Hr
CHINSAN
2nd source
C925 067G-2046812KT CS CAP 680uF 10V 8*11 mm
067G-2046812LT CAP CS 680UF 20% 10V 8*11.5 2nd source
C809 067G-4153309LT EC 33uF +-20% 100V 8*11.5 4000H LELON
067G-4153309KT EC 33uF -20% 100V 8*12 4000H ELITE 2nd source
C801 067G215D3314KT
EC 330uF +-20% 25V 10*12 4000Hr
CHINSAN
C918,C919 067G215D6814KT
EC 680uF +-20% 25V 10*20 4000Hr
CHINSAN
067G215D6814LT
EC 680uF -20% 25V 10*20 4000Hr
LELON
2nd source
C922,C931 067G215S4713KT
EC 470uF +-20% 16V 10*13 4000Hr
CHINSAN
067G215S4713LT
EC 470uF -20% 16V 10*12.5 4000Hr
LELON
2nd source
C913 067G215Y4707KT 47uF 50V
067G215Y4707LT LOW ESR EC 47uF 50V M 6.3*11mm 2nd source
J810 071G--55--9--T FERRITE BEAD
FB801,FB802,FB901 071G--55-29 FERRITE BEAD
071G--55-29--X
BEAD 3.5*2.2*0.8 45R -25%
3BDR3522-453A ASET
2nd source
F801 084G--56--3--C
FUSE 3.15A 250V MST 3.15A 250V
CONQUER
F901,F902,F903 084G--56--5--C FUSE 5A 250V MST 5A 250V
084G--56--5--B FUSE 5A 250V SS-5-5A-AP 2nd source
ZD901 093G--39A6852T
DIODE ZD DIODES MTZJ22B 21.51V/0.5W
DO-34 SEMTECH
093G--3916352T DIODE ZD TZX22B 22V/05W DO-35 2nd source
