LE32A0320
Item Description
2 DECO_BEZEL
3 SPEAKER
4 PANEL
5 BKT_STAND
6 COVER_STAND
7 KEY
8 REAR_COVER
9 BASE
10 KEY BOARD
11 IR BOARD
12 MAIN BOARD
13 BKT_IO
14 POWER BOARD
Item Part No. Description Q’ty
15 BOLT 22 0M1G1030 8 47 CR3 SCREW REAR COVER-PANEL 8
16 BKT_BTM 23 0M1G1030 8 47 CR3 SCREW REAR COVER-DECO_BEZEL 6
17 INSULATING SHEET 24 0M1G1730 8120
SCREW MAIN BOARD-BOLT/MAIN BOARD-BKT_IO-PANEL/
BKT_IO-PANEL/POWER BOARD-PANEL
11
18 BOLT 25 0M1G1740 10225 CR3 SCREW BKT_STAND-PANEL 4
19 CABLE TIE 26 0Q1G 940 8 47 CR3 SCREW REAR COVER-DECO_BEZEL 2
20 FOOT PAD 27 0Q1G 940 12 47 CR3 SCREW REAR COVER-DECO_BEZEL 4
21 BKT_STAND 28 0M1G1740 16225 CR3 SCREW BASE-STAND 4
29 STAND 30 0M1G1740 10225 CR3 SCREW REAR COVER-BKT_STAND 4
