LE39A0320

Item Description

2 PANEL

3 DECO_BEZEL

4 DECO_BEZEL

6 IR BOARD

9 SPEAKER

10 COVER_STAND

11 BKT_STAND

Item Part No. Description Q‘ty

13 INSULATING SHEET 5 0M1G1730 6120 SCREW DECO_BEZEL-PANEL/IR BOARD-DECO_BEZEL 5

14 POWER BOARD 12 0M1G 940 6125 SCREW BKT_STAND-PANEL 4

16 BOLT 15 0M1G1730 8120 SCREW POWER BOARD-PANEL 4

17 BOLT 19 0M1G1730 8120 SCREW BKT_IO-PANEL 1

18 BKT_IO 22 0M1G1730 8120 SCREW MAIN BOARD-BOLT-PANEL 1

20 MAIN BOARD 23 0M1G1730 8120 SCREW BKT_IO-MAIN BOARD-PANEL 1

21 BKT_BTM 24 0M1G1730 8120 SCREW MAIN BOARD-PANEL 1

25 BKT_HINGE 27 0Q1G1030 6120 SCREW BKT_HINGE-STAND 1

26 STAND 30 0Q1G 130 6120 XL SCREW BASE-BKT_BASE 2

28 BASE 31 0M1G1740 10225 CR3 SCREW BKT_BASE-STAND 4

29 BKT_BASE 33 0M1G1740 10225 CR3 SCREW BKT_HINGE-BKT_STAND 4

32 FOOT PAD 37 0M1G1030 6 47 CR3 SCREW REAR COVER-PANEL 8

34 KEY 38 0Q1G 940 10 47 CR3 SCREW REAR COVER-DECO_BEZEL 4

35 KEY BOARD 39 0Q1G 940 8 47 CR3 SCREW REAR COVER-DECO_BEZEL-COVER_STAND 2

36 REAR_COVER 40 0M1G1730 8120 SCREW REAR COVER-AC SOCKET 1
