NOT
ICE: In case the tyre is completely void of air, slightly lift the car with the car jack.
Read off the current values from the manometer. NOTICE: The pressure should also
be checked with another separate tyre gauge. If the required pressure is reached, turn
off the compressor, open the quick release valve and remove it from the valve. Put the
valve cap back on.
- Inflation of leisure wear like balls, airbeds, etc.
- Check the manufacturers parameters for the pressure.
- Remove valve cap.
- Carefully shove the appropriate adapter over the quick release valve as far as
possible and lock it.
- Shove the other end of the adapter as far as possible over the valve of the product
you want to inflate.
- Bring the ON/OFF switch into ON position.
- Read off the current values from the manometer. If the required pressure is reached,
turn off the compressor, remove the adapter from the valve and put the valve cap
back on.
Storage
The power pack can be stored in any position. Make sure, that the battery clamps are
kept tightly in the provided cases. Store it at room temperature. If the power pack is not
in use over a longer period, charge it every 2 month at winter time and every month in
summer time.
Specification
Battery: 10 AH lead acid accumulator, rechargeable, maintenance free
Outlet socket: 12V nominal
Compressor: 260 PSI/ 18 bar
Jump start: 400 amp.
Charging time:
Initial charging 24 hours with power supply, further chargings 20
hours with power supply and 6-8 hours with 12V cigarette lighter
lead
Weight: approx. 4,1kg
Dimension: L/B/H: approx. 250mm x approx. 230mm x approx. 160mm
Storage: At cool and dry place
D
ysfunction
Dysfunction Reason Remedy
Clamps fixed improperly
Remove clamps and fix
again
Engine does not start
Weak battery
Wait 3-4 minutes and start
again
