Page #25 background image
Installation and Quick Start 21
Specifications
Electrical
Input voltage, nominal 24 VDC
Maximum total
current draw
130 mA @ 19-30 VDC (with standard sensor attached)
Temperature accuracy ±2ºC (±3ºF) within the range of 0 to 40ºC (32 to
104ºF)
Humidity accuracy ±8% RH within the range of 10 to 90% RH at 25ºC
(77ºF)
±8% RH within the range of 30 to 80% RH at
temperatures from 15 to 30ºC (59 to 95ºF)
Current capacity of
relay contacts
1 A @ 30 V AC/DC (for AP9618 and AP9619 only)
+12 VDC output 25 mA maximum current (for AP9618 and AP9619
only)
Sensor zone input
response time
200 mS
Physical
Size (H × W × D) 1.50 × 4.75 × 4.25 in (3.81 × 12.07 × 10.80 cm)
Weight 0.30 lb (0.14 kg)
Shipping weight 2 lb (0.91 kg)

Other manuals for APC AP9617

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the APC AP9617 and is the answer not in the manual?

APC AP9617 Specifications

General IconGeneral
TypeNetwork Management Card
ModelAP9617
Data Link ProtocolEthernet, Fast Ethernet
Network Ports Qty1
Network ProtocolsTCP/IP, HTTP, HTTPS, SNMP, Telnet, SSH
ManagementSNMP
CompatibilitySmart-UPS
Remote Management ProtocolSNMP, HTTP, HTTPS, Telnet, SSH
SecuritySSL, SSH
Operating Temperature0 to 45 °C
Storage Temperature-15 to 65 °C
Humidity0 to 95% non-condensing
PortsRJ-45 Ethernet
