990-4618A-001 InRow™ Chilled Water Air Conditioners Technical Specifications 1
Technical Data
Model Identification
Model identification label location
Model Width
Range
of Capacity
Humidifier/
Reheat
Voltage Phase Frequency
Power
Connection
ACRC100 300 mm Up to 30 kW No 100–120V 1 50/60 Hz NEMA L5-20P
ACRC103 300 mm Up to 30 kW No 200–240V 1 50/60 Hz IEC-309 16A
ACRC500 600 mm Up to 70 kW No 200–240V 3 50/60 Hz
HARDWIRED
Optional:
NEMA L21-20P
ACRC501 600 mm Up to 70 kW No 460–480V 3 50/60 Hz HARDWIRED
ACRC502 600 mm Up to 70 kW No 380–415V 3 50/60 Hz
HARDWIRED
Optional:
NEMA IEC-309 16A
ACRP500 600 mm Up to 70 kW Yes 200–240V 3 50/60 Hz HARDWIRED
ACRP501 600 mm Up to 70 kW Yes 460–480V 3 50/60 Hz HARDWIRED
ACRP502 600 mm Up to 70 kW Yes 380–415V 3 50/60 Hz HARDWIRED
Nameplate
Nameplate
300 mm 600 mm
Rear

APC InRow Specifications

General

Refrigerant	R410A
Mounting	In-row
Humidity Range	20% to 80% RH
Airflow	Varies by model (e.g., 1, 500 to 6, 000 CFM)
Power Supply	208/230V or 400/480V, 3-phase
Operating Temperature Range	65°F to 95°F (18°C to 35°C)
