APELL APS62CS - Built Under Kit Assembly

DRYER
BUILT UNDER KIT ASSEMBLY INSTRUCTIONS
1) Remove 3 screw ( A ) and Pull out the top plate.
2) Remove the 4 support bracket (If exist) ( B ) by
unscrewing the screws shown in the gure.
3) Unscrew the 2 screws ( C ) located on the back top
corners of the dryer and the 3 screws ( D ) which xed
front panel.
4) Put the foam seal to the built under kit as shown in the
picture.
5) Put the built under kit and screw the built under
kit on the dryer with 5 screw.
C
D
B
A
A
A
Foam Seal
