5.3.3 Turning off UPS with mains
1) To turn off the inverter of UPS by pressing button continuously for more than 3sand the
buzzer will beep for 3s. The UPS willturn into Bypass mode at once.
2) When completing the above action, UPS output voltage is still present.In order to cut off the
UPS output, simply cut off the mainspower supply. A few seconds later, LCD display shuts
down and no output voltage is available from the UPS output terminal.
5.3.4 Turning off UPS without mains
1) To power off the UPS by pressing button continuously for more than 3s, and the buzzer
will beep 3s. The UPS will cut off the output at once.
2) A few seconds later, LCD shuts down and no voltage is available fromthe UPS output.
5.4 LCD Operation
Except the default UPS status summary screen,the user could get moreuseful information
about UPS current status, detailed various measurements, old eventswhich ever occurred,
UPS own identification, and could change the settings to fit the user own requirements,
optimize the function of UPS.
5.4.1 The main menu
In the default UPS status summary screen, when pressing
or
<1s, the detailed
information about alarm, the parallel system, battery would be shown.
In the default UPS status summary screen, when pressing >1s, the display would
enter main menu tree.
The main menu tree includes six branches: UPS status menu, event log menu,
measurement menu, control menu, identification menu, setting menu.
