Apollo FOX User Manual

17
2.8 Loading
This section contains values of payload at which the aircraft can be safely operated.
Aircraft weighing procedures and computations to determine range of safe payload
are included.
Table of Weights
Max. Take-Off Weight No Baggage 5 kg Baggage 10 kg Baggage
450 kg Max. Crew Weight Max. Crew Weight Max. Crew Weight
Empty 275 kg 175 kg 170 kg 165 kg
+ Fuel 30 l 154 kg 149 kg 144 kg
+ Fuel 60 l 133 kg 128 kg 123 kg
2.9 Flight Load Factors
At take-off weight of 450 kg
Maximum positive centre of gravity load factor: + 4 g
Maximum negative centre of gravity load factor:- 2 g
1
2
3
4
-1
-2
0
A
G
50 100 150 200
V[km/h]
n
V
V
V
V
V
F
A C
G
NE
V
V
S1
S0
Load envelope for maximum take-off weight of 450 kg

Apollo FOX Specifications

General

Manufacturer	Apollo Ultralight Aircraft
Type	Light Sport Aircraft
Seating capacity	2
Height	2.3 m
Engine	Rotax 912
Stall speed	65 km/h
Service Ceiling	3, 000 m
